Room controllers for 2 or 4 pipe system with automatic speed and changeover
Industrietechnik

Room controllers for 2 or 4 pipe system with automatic speed and changeover

2- and 4-pipe and 3-speed fan control with for room temperature regulation.

Specifications
Software & documentation

Articles

(1 st)
  • DB-TA-387-10A - Regin
    DB-TA-387-10A
    On/off button
    Yes
    Speed selection button
    No
    Change-over function, season
    Auto
    3 speeds
    Auto
    Sensor
    NT0220-NTC10-02

Specifications

Specifications for Room controllers for 2 or 4 pipe system with automatic speed and changeover
Supply voltage 230 V AC ±10%, 50/60 Hz
Load Max. 6 A
Output 5 relays 8 A 230 V AC
Power consumption 1 W
Sensor NTC 10K
Ambient temperature 0…40°C
Ambient humidity 10…90 % RH (non-condensing)
Setpoint 12…28°C
Hysteresis 0.4 K
Storage temperature -20…+70°C
Storage humidity < 95% RH
Casing ABS fireproof according to UL94 V-0 color (RAL 9010)
Weight 210 g
Dimensions 144 x 82 x 34mm
Protection class IP30
Isolation class II

Software & documentation

Product sheet

Instructions
